- Size: 11
- Place of Origin: CHINA
- Brand Name: SUNRISE
- Model Number: TKH1412
- Weight: 7500.000 kg
Specifications:
Power: 3phrase AC 380V50Hz
Power: 13.4Kw
Size about: 2000X2000X1200 (mm)
Spindle speed: 460r/min
Two spindle axis
Automatic feeding rates:100-500mm/min
Workpiece process
Back-off process:
1.Adjust the depth of back-off, turn on the hand wheel, according to different sizes of angle steel, adjust it yourself, lock it.
2.Press the spindle start button to start the back-off spindle.
3.Press the spindle feeding button to start feeding.
4.Put the angle steel on the feeding rack, which is driven by the stick of the rack, automatically feeding and production.
5.After the production, the end product will be automatically sent out of the feed frame.
Configurations:
1.Electrical components are brand of Schneider and Omron, high quality, performance stable.
2.The main spindle bearing is NSK from Japan, high precision, long life.
3.The electrical motors are Siemens which can ensure high quality and long life.
4.Reducer is SEW brand which are imported from the European countries, the world first-class quality.
5.Dynamic head chooses high speed milling head which made in Japan.
Main component list
No | Name | Type | Quantity |
1 | Flat cutter | 100 | 1 |
2 | ARC cutt er | 100 | 1 |
3 | spindle motor | Y112M-4 | 2 |
4 | reducing motor | NMRV050-NMRV110 | 2 |
5 | reducing motor | Y110-200 | 1 |
6 | slide rod | HGW35CA | 6 |
7 | PLC | DVP-64EHOOR2 | 1 |
8 | Text display | TP04G-BL-C | 1 |
9 | Inverter | VFD-015M | 1 |
10 | Micro- off | C65N 3P C32A | 2 |
11 | C65N 3P C2A | 2 | |
12 | Micro- off | C65N 3P C10A | 1 |
13 | Micro- off | C65N 3P C6A | 3 |
14 | Micro- off | C65N 2P C6A | 1 |
