- Size: 12
- Place of Origin: CHINA
- Brand Name: SUNRISE
- Model Number: TBS1000
- Weight: 6000.000 kg
Applicable industry:
Used for the sawing of H-shape steel, box beams, channel steel, angle steel and round steel of steel structure, bridge, three dimensional garages and petrol platform industries.
Product feature:
■Double column design equipped with strong lathe bed, with fine function of absorbing vibration during high speed sawing.
■Can rotate itself and no need to rotate for longer work piece when beveling for 0°~45°, can keep the continuity of production.
■Saw blade driving with greater motor power and good transmission. Used for the specialized processing of various section steel of steel structure industry.
■Saw blade hydraulic automatic tensioning device, keep saw blade stable during high speed rotation and can extend life of saw blade.
■Small aperture, high precision, and greatly reduce material consumption.
■Laser alignment function and advanced and retreated structure slightly adjusted with hand, convenient for cutting accurately.
■Automatic coolant compatible with blade could make blade lubricant and reduce the temperature of blade.
■PCL control, sawing linear velocity can be adjusted by transducer motor and sawing feeding speed also can be adjusted by hydraulic stepless adjustment. This greatly promotes production efficiency.
■Key machine, hydraulic pressure and electric components are chosen famous products domestic and abroad.
Specifications:
sawing force (mm) | round steel | 90 ° | Φ 75 mm ~ Φ 500 mm | |
45 ° | Φ 75 mm ~ Φ 500 mm | |||
H beam / square steel | 90 ° | 200x75 mm~1000 x 500 mm | ||
45 ° | 200 x 75 mm~70 0 x 5 00 mm | |||
saw blade size (mm) | T hickness :1.6 W idth :54 Length : 76 00 | |||
saw blade lineal speed ( m/min ) | 20 ~ 80 ( adjustable ) | |||
M otor power | saw blade | 7.5kw | ||
hydraulic | 2.2kw | |||
rotary table | 0.04kw | |||
cooling system | 0.12kw | |||
bench height | 800mm | |||
feeding speed | stepless feeding | |||
rotation angle | 0° ~ 45° | |||
overall dimension | Width: 4000 mm | |||
Length: 2 300 mm | ||||
Height: 2 55 5mm | ||||
gross weight of machine | ≈ 6 0 00kg | |||
Total power | 15kW |
